KPM II Stack-Mode Electronic Seed Monitor
ITEM
PART NO.
QTY.
DESCRIPTION
7
GD8770
1
Bracket
8
G10001
G10229
G10101
2
2
2
Hex Head Cap Screw, ⅜"-16 x 1"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
9
GD8771
1
Spring Wave Washer
10
GA9857
GR1631
GR1632
1
-
-
SMM Backlit Console W/Mounting Bracket and Dust Plug (Item 36)
Mounting Bracket, KPM II Stack-Mode and SMM Consoles
Console Mounting Bracket Hardware Package (Includes 2 Knobs and ¼" Hardware)
11
GA7856
1
Power Lead Adapter
12
GA9144
-
Monitor/Radar Adapter Cable, 10"
13
G1K267
-
Power Lead Adapter Connector Kit, Includes: (1) Cable Clamp, (1) 3-Pin Connector,
(3) Male Terminal Pins
14
G1K268
-
Console Cable Connector Kit, Includes: (1) Cable Clamp, (1) 3-Pin Connector, (1)
Lock Ring, (3) Female Terminal Pins
15
GA10575
GR1391
GR1393
GA10601
GD7639
-
-
-
-
-
KPM II Backlit Console W/Mounting Bracket, Fuse Holder and Fuse, Power Lead
Adapter (Item 11), Brush (Item 23), Dust Plug (Item 34) and Monitor/Radar Adapter,
10" (Item 12)
Mounting Bracket, KPM II
Console Mounting Bracket Hardware Package (Includes 4 Knobs and ¼" Hardware)
Fuse Holder
Fuse
16
G1K322
-
4-Pin Connector Kit W/Male Housing, (4) Female Socket Contacts and (1) Cable Clamp
17
---
-
Included In Planter Wiring Harness, See Item 2, on
18
GA8021
GA8022
GA7850
GD11993
-
-
-
-
Planter Harness W/Dust Caps, 4 Row (7 Connectors)
Planter Harness W/Dust Caps, 6 Row (9 Connectors)
Planter Harness W/Dust Caps, 8 Row (12 Connectors)
Dust Cap
19
GA19961
GA19960
-
-
Seed Tube W/Computerized Sensor
Seed Tube (With Holes For Sensor Installation)
20
GA7859
1
Magnetic Distance Sensor Adapter (Analog To Digital)
21
GA8047
GA9979
-
-
Dust Plug (Black)
Dust Plug (Blue)
22
G10022
G11385
G10227
G10103
2
2
2
2
Hex Head Cap Screw, ¼"-20 x ½"
Flat Washer, ¼" SAE
Lock Washer, ¼"
Hex Nut, ¼"-20
23
GR0594
-
Brush
24
GR0586
1
Radar Y-Cable (Used To Connect Radar Distance Sensor For Multiple Functions)
25
GA7857
-
Adapter Harness, 1'
26
GA7854
GA7855
GD11993
-
-
-
Extension Harness W/Dust Cap, 15'
Extension Harness W/Dust Cap, 30'
Dust Cap
27
GA7853
GD11993
-
-
Junction Y-Harness W/Dust Cap
Dust Cap
28
G1K321
-
2-Pin Female Connector Kit (Black), Includes: (3) 2-Pin Female Housings, (6) Pin
Contacts, (6) Seals
29
G1K320
-
2-Pin Male Connector Kit (Black), Includes: (3) 2-Pin Male Housings, (6) Socket
Contacts, (6) Seals
30
G1K248
G1K362
-
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
31
G1K252
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
G1K363
-
3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
32
GD11089
-
Sealing Plug
33
G1K249
-
Acre Counter Switch Kit
34
GA8046
GA9978
-
-
Dust Plug (Black)
Dust Plug (Blue)
A
GA6147
-
Magnetic Distance Sensor and Mounting Package (Items 4-9)
