Kinze 3000 Rigid Frame Planter Rev. 5/14 - Manual (Page 85)

ITEM PART NO. QTY. DESCRIPTION
1 GA7856 1 Power Lead Adapter
2 G1K267 - Power Lead Adapter Connector Kit, Includes: (1) Cable Clamp, (1) 3-Pin Connector,
(3) Male Terminal Pins
3 G1K268 - Console Cable Connector Kit, Includes: (1) Cable Clamp, (1) 3-Pin Connector, (1)
Lock Ring, (3) Female Terminal Pins
4 GA10570
GR1390
GR1392
GA10601
GD7639
1
-
-
-
-
KPM I Backlit Console W/Mounting Bracket, Fuse Holder and Fuse, Power Lead
Adapter (Item 11), Brush (Item 23) and Dust Plug (Item 34)
Mounting Bracket, KPM I
Console Mounting Bracket Hardware Package (Includes 2 Knobs and ¼" Hardware)
Fuse Holder
Fuse
5 --- - Included In Planter Wiring Harness, See Item 2, on page P79
6 GA8021
GA8022
GA7850
GD11993 -
-
-
- Planter Harness W/Dust Caps, 4 Row (7 Connectors)
Planter Harness W/Dust Caps, 6 Row (9 Connectors)
Planter Harness W/Dust Caps, 8 Row (12 Connectors)
Dust Cap
7 GA19961
GA19960 -
- Seed Tube W/Computerized Sensor (Shown)
Seed Tube (With Holes For Sensor Installation)
8 GR0594 - Brush
9 G10022
G11385
G10227
G10103 2
2
2
2 Hex Head Cap Screw, ¼"-20 x ½"
Flat Washer, ¼" SAE
Lock Washer, ¼"
Hex Nut, ¼"-20
10 GA7857 - Adapter Harness, 1'
11 GA7854
GA7855
GD11993 -
-
- Extension Harness W/Dust Cap, 15'
Extension Harness W/Dust Cap, 30'
Dust Cap
12 GA7853
GD11993 -
- Junction Y-Harness W/Dust Cap
Dust Cap
13 G1K248
G1K362
-
-
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
3-Pin Female Connector Kit (Blue), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
14 G1K252
G1K363
-
-
3-Pin Male Connector Kit (Black), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
3-Pin Male Connector Kit (Blue), Includes: (3) 3-Pin Male Housings, (9) Socket
Contacts, (9) Seals
15 GD11089 - Sealing Plug
16 GA8046
GA9978 -
- Dust Plug (Black)
Dust Plug (Blue)
17 GA8047
GA9979 -
- Dust Plug (Black)
Dust Plug (Blue)
KPM I Electronic Seed Monitor
TM
Model 3000 M0188-02
Rev. 5/14 P82
