Liquid Fertilizer Piston Pump Drive
ITEM PART NO. QTY. DESCRIPTION
26 GD5990 1 Shaft, 74"
27 GD3839 1 Coupler, 2"
28 G10602 1 Spring Pin, ¼" x 1½"
29 G10460 1 Cotter Pin, ¼" x 2"
30 G10130
G10923 -
- Square Head Machine Bolt, 5∕16"-18 x 1¾"
Flange Nut, 5∕16"-18, No Serration
31 G11075 2 External Inverted Snap Ring, ⅞"
32 G10496 2 External Inverted Snap Ring, 1½"
33 G10629 1 Elbow, 90°, 1¼" NPT To Barb
34 --- - See “Liquid Fertilizer Tanks, Saddle, Mounts, Hoses, and Fittings, 4 Row” on page P109
See “Liquid Fertilizer Tanks, Saddles, Mounts, Hoses, and Fittings, 6 and 8 Row” on page P111
35 G10615 1 Reducing Bushing, 1½" Male NPT To 1¼" Female
36 G10995 1 Reducing Bushing, 1" Male NPT To ¾" Female, Stainless Steel
37 G10292 - Pipe Plug, ¼" NPT
38 GA3893
GR0880
GR0881
GR0882
GR0883 1
-
-
-
-
Strainer Complete
Screen, No. 40 Mesh
Gasket
Y-Body
End Cap
39 G10994 1 Close Nipple, ¾" NPT, Stainless Steel
40 GD14431 1 Handle
41 GD14427 1 Tightener Shaft, 4⅞"
42 G11078 1 Vinyl Cap
43 GD14432 1 Sleeve, 1¼"
44 GD19343 1 Release Collar, R.H.
45 GD14413 1 Torsion Spring, L.H. (Used On R.H. Wrap Spring Wrench)
46 G11237 1 Reducing Bushing, 1½" Male NPT To ¾" Female
47 --- - See “Liquid Fertilizer Piston Pump Uses 18 Tooth Sprocket” on page P121
A G1K269 - Lock Clamp Kit (Items 17 and 30)
B G1K378 - Wrap Spring Wrench Replacement Kit, Blue Collar, R.H., (Items 13, 15, 31, 32 and
41-46)
