Hitch and Frame Assembly/Safety Chain
ITEM PART NO. QTY. DESCRIPTION
11 G10005
G10107 1
1 Hex Head Cap Screw, ⅝"-11 x 1¾"
Lock Nut, ⅝"-11
12 G10017
G11389
G10111 1
1
1 Hex Head Cap Screw, ½"-13 x 1½"
Washer, ½" SAE
Lock Nut, ½"-13
13 GA7909 1 Jack Adjustment Bracket
14 GD5888 1 Spring
15 GA8670 1 Hitch
16 G10048
G10108 2
2 Hex Head Cap Screw, ⅜"-16 x 2"
Lock Nut, ⅜"-16
17 GD5875 2 Hose Clamp
18 GA5197 - Spacer
19 G10048
G10108 -
- Hex Head Cap Screw, ⅜"-16 x 2"
Lock Nut, ⅜"-16
20 G10993
G10647 4
4 Hex Head Cap Screw, 1"-8 x 8½", Grade 8
Hex Nut, 1"-8, Grade 8
21 GD6027 - Hose Clamp, ¾" x 2 ½" x 2½"
22 A8011
A8012
A8013
A8014
A8015 1
-
-
-
-
Double Frame Toolbar, 7" x 5" x 120", 4 Row 30" (Non-Stock Item)
Double Frame Toolbar, 7" x 5" x 144", 4 Row 36"/38" (Non-Stock Item)
Double Frame Toolbar, 7" x 5" x 180", 6 Row 30" (Non-Stock Item)
Double Frame Toolbar, 7" x 5" x 220", 6 Row 36"/38" (Non-Stock Item)
Double Frame Toolbar, 7" x 5" x 240", 8 Row 30" (Non-Stock Item)
23 GA9007
GD6027
G10048
G10108 -
-
-
- Hitch Extension W/Hose Clamps and Hardware
Hose Clamp, ¾" x 2 ½" x 2½"
Hex Head Cap Screw, ⅜"-16 x 2"
Lock Nut, ⅜"-16
24 G10903 - Cap Plug
25 G10895
G10112 8
8 Hex Head Cap Screw, ¾"-10 x 8½"
Lock Nut, ¾"-10
26 GD1113
G10230
G10104 -
-
- U-Bolt, 5" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
27 GA4265 - Straight Extension
28 G10061
G11387
G10108 4
4
4 Hex Head Cap Screw, ⅜"-16 x 3½"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
29 G11085 4 Flanged Cap Screw, 12 Point, 1"-14 x 3"
30 GA9427 - Hitch/Center Extension, L.H., Straight, 24"
31 GA9426 - Hitch/Center Extension, R.H., Straight, 24"
32 GA9439 - End Extension, L.H.
33 GD1114
G10230
G10104 -
-
- U-Bolt, 7" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
34 A8016
A8017
A8018
A8019
A8020 1
-
-
-
-
Toolbar, 7" x 7" x 120", 4 Row 30" (Non-Stock Item)
Toolbar, 7" x 7" x 144", 4 Row 36"/38" (Non-Stock Item)
Toolbar, 7" x 7" x 180", 6 Row 30" (Non-Stock Item)
Toolbar, 7" x 7" x 220", 6 Row 36"/38" (Non-Stock Item)
Toolbar, 7" x 7" x 240", 8 Row 30" (Non-Stock Item)
35 GB0329 2 Hitch Clamp
36 GA9438 - End Extension, R.H.
