P118 – Kinze 3000 Rigid Frame Planter Rev. 5/14 User Manual
Page 121
ITEM
PART NO.
QTY.
DESCRIPTION
1
GR1389
1
Sprocket, 18 Tooth
2
G10688
2
Square Head Set Screw, ⅜"-16 x ⅝"
3
GR1425
1
Repair Kit
4
GR1427
2
Bearing
5
GR1420
1
Woodruff Key, ⅜"-16 x 1¾"
6
GR1167
1
Square Head Cap Screw, ⅜"-16 x 1¾"
7
G10043
4
Hex Head Cap Screw, 5∕16"-18 x ¾"
8
GR1168
1
Scale
9
G10108
1
Lock Nut, ⅜"-16
10
G10693
3
Hex Socket Head Set Screw, 5∕16"-18 x ⅜"
11
GR1165
1
Arm
12
GR1114
1
Flange
13
GR1116
1
Bearing
14
GR1421
1
Crankshaft
15
GR1118
2
Setting Arm Key
16
---
-
See “Liquid Fertilizer Piston Pump Drive” on page P113
17
GR1424
1
Adjustment Wrench
A
GA8069
-
Piston Pump Complete W/18 Tooth Sprocket (Model LM-2455-R), Includes
Crankcase Assembly On This Page and Cylinder Assembly on
Liquid Fertilizer Piston Pump (Crankcase Assembly) Uses 18
Tooth Sprocket
