Kinze 3000 Rigid Frame Planter Rev. 5/14 - Manual (Page 17)

Hopper Support and Meter Drive
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GB0314 2 Hopper Mount
2 GB0218 4 Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
3 G10752
G11391
G11514 2
2
2 Hex Head Cap Screw, ⅝"-18 x 2¼"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-18
4 G10751
G11391
G11514 2
2
2 Hex Head Cap Screw, ⅝"-18 x 1¾"
Flat Washer, ⅝" SAE
Lock Nut, ⅝"-18
5 G10602 1 Spring Pin, ¼" x 1½"
6 G10567 1 External Retaining Ring, ⅝"
7 GD11239 1 Knob
8 G10338
G10620 2
2 Carriage Bolt, 5∕16"-18 x 1¼"
Serrated Flange Nut, 5∕16"-18
9 GB0331 1 Clutch Adapter Plate
10 G10061
G11387
G10108 1
2
1 Hex Head Cap Screw, ⅜"-16 x 3½"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
11 G10309
G10621 2
2 Carriage Bolt, ¼"-20 x ⅝", Grade 2
Serrated Flange Nut, ¼"-20
12 GA2007 1 Hopper Hold Down Latch
13 GA10155 1 Hopper Support
14 GA10137 1 Double Sprocket and Bearing, Drive Clutch, 11/19 Tooth
15 GD11413 1 Spring
16 GD15747 1 Shaft
17 GB0278 1 Coupler
18 G10546 1 Spring Pin, 3∕16" x 1¼"
A GA10151 - Meter Drive Assembly Complete, 11/19 Tooth (Items 5-7 and 14-18)
TM
Model 3000 M0188-02
Rev. 5/13 P14
