Kinze 3000 Rigid Frame Planter Rev. 5/14 - Manual (Page 43)

ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 G11010 2 Hex Head Cap Screw, ¾"-10 x 12"
2 GA9844 1 Plate W/Angle
3 G10039 4 Hex Head Cap Screw, ½"-13 x 1¾"
4 GA9131 1 Coulter Frame
5 G10007
G10107 4
4 Hex Head Cap Screw, ⅝"-11 x 1½"
Lock Nut, ⅝"-11
6 G10400
G10112 1
1 Hex Head Cap Screw, ¾"-10 x 6½"
Lock Nut, ¾"-10
7 GD12826 1 Spring Anchor Bar
8 G10574
G10111 4
4 Carriage Bolt, ½"-13 x 1¼"
Lock Nut, ½"-13
9 GD12827 2 Adapter
10 GA8641
GA8603
GD11652 1
1
1 Hub W/Bearing and Retaining Ring
Bearing, Double Row
Retaining Ring, 27∕16"
11 GD7803
GD7804
GD9254 1
-
-
Disc Blade, Fluted, 1", 8 Flutes (Shown)
Disc Blade, Bubbled, 1"
Disc Blade, Fluted, ¾", 13 Flutes
12 GB0213 2 Spring Seat
13 GD12817 2 Compression Spring
14 GD12829 1 Sleeve
15 G10046
G10107 1
1 Hex Head Cap Screw, ⅝"-11 x 5"
Lock Nut, ⅝"-11
16 GA9845
G10643 1
-
Coulter Arm W/Grease Fitting
Grease Fitting, 45°, ¼"-28
17 G10011
G10107 1
1 Hex Head Cap Screw, ⅝"-11 x 5½"
Lock Nut, ⅝"-11
18 GB0218 3 Bushing, 21∕32" I.D. x ⅞" O.D. x 19∕32" Long
19 GD1132 2 Dust Cap
20 G10010
G10503 2
2 Hex Head Cap Screw, ⅝"-11 x 3"
Hex Jam Nut, ⅝"-11, Grade 2
21 GD10552 2 Wheel, 12 Tine, ⅜" x 12"
22 GA5654
GA2014 2
-
Hub W/Bearings
Bearing
23 GD9724 2 Backing Plate
24 G10133
G10109 12
12 Hex Head Cap Screw, 5∕16"-18 x 1½"
Lock Nut, 5∕16"-18, Grade 8
25 G10213 2 Machine Bushing, ⅝" (.030" Thick)
26 GA9862
G10765 2
-
Weed Guard W/Spring Pin
Spring Pin, ¼" x 1"
27 GA9865 1 Mount
28 GA9861 1 Cam
29 GD10519 1 Spring
30 G10974 1 Lock Nut W/Nylon Insert, ½"-13
31 G10005
G10107 1
4 Hex Head Cap Screw, ⅝"-11 x 1¾"
Lock Nut, ⅝"-11
32 GA15312 1 Cam Support
33 G10014
G10102 1
1 Hex Head Cap Screw, ½"-13 x 1"
Hex Nut, ½"-13
34 G10011
G11391
G10730 2
2
2 Hex Head Cap Screw, ⅝"-11 x 5½"
Flat Washer, ⅝" SAE
Lock Nut W/Nylon Insert, ⅝"-11
35 GD14170 2 Sleeve, 3"
36 GB0387 2 Wheel, 12 Tine, ⅜" x 12"
A GA7446
GA7445 -
- Wheel Assembly, 12 Tine, R.H. (Items 21-24) (Shown)
Wheel Assembly, 12 Tine, L.H. (Items 21-24)
B GA12236
GA12235 -
- Wheel Assembly, 12 Tine, R.H. (Items 22, 23, 24 and 36) (Shown)
Wheel Assembly, 12 Tine, L.H. (Items 22, 23, 24 and 36)
Frame Mounted Coulter W/Residue Wheels
TM
Model 3000 M0188-02
