ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
1 GD0453-03 1 Extension Tube, 50", 6 Row 36"/38" and 8 Row 30"
2 G11396 2 Flat Washer, 1¼" SAE
3 GA5173
G10641 1
-
Arm W/Grease Fittings, First Stage
Grease Fitting, ⅛" NPT
4 --- - See “Row Marker Cylinder, 6 Row 36"/38" and 8 Row 30"” on page P69
5 GD15386
G10460 1
1 Pin, 1¼" x 7⅝"
Cotter Pin, ¼" x 2"
6 GD5875 1 Hose Clamp
7 G10133
G10109 1
1 Hex Head Cap Screw, 5∕16"-18 x 1½"
Lock Nut, 5∕16"-18, Grade 8
8 GD0652
G10460 1
2 Pin, 1¼" x 9½"
Cotter Pin, ¼" x 2"
9 G10879 4 Flanged 12 Point Bolt, ⅝"-11 x 2", Special Hardened
10 GA5130 1 Mount
11 GD3214
G10460 1
2 Pin, 1¼" x 12¼"
Cotter Pin, ¼" x 2"
12 GD2161
G10460 1
2 Pin, 1¼" x 8¼"
Cotter Pin, ¼" x 2"
13 GD2721
G10228
G10102 1
2
2 U-Bolt, 2" x 2" x ½"-13
Lock Washer, ½"
Hex Nut, ½"-13
14 GA5190
GA5188 1
-
Arm, Second Stage, 35", 6 Row 36"/38"
Arm, Second Stage, 46", 8 Row 30"
15 GD0752-41 - Sleeve, 1" (If Applicable)
16 GA11766
G10640
G10460 -
-
1
Pin W/Grease Fitting, 1¼" x 1113∕16"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 2"
17 GA11591 - Arm, First Stage
18 GA11767
G10640
G10460 -
-
1
Pin W/Grease Fitting, 1¼" x 9½"
Grease Fitting, ¼"-28
Cotter Pin, ¼" x 2"
Row Marker Assembly, Two-Fold Low Profile
6 Row 36"/38" and 8 Row 30"
TM
Model 3000 M0188-02
Rev. 6/11 P64
