Kinze 3000 Rigid Frame Planter Rev. 5/14 - Manual (Page 11)

Covering Discs/Single Press Wheel
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 G10001
G11387 1
1 Hex Head Cap Screw, ⅜"-16 x 1"
Flat Washer, ⅜" SAE
2 GB0268 1 Wheel Arm Stop
3 G10801
G10315
G10102 2
-
2
Carriage Bolt, ½"-13 x 2¼"
Carriage Bolt, ½"-13 x 2½" (Used W/Straight Drop In-Furrow Granular Chemical Bracket)
Hex Nut, ½"-13
4 GA2054 1 Spring
5 GB0239 2 Eccentric Bushing
6 G10102 1 Hex Nut, ½"-13
7 G10015 1 Adjusting Bolt, ½"-13 x 5"
8 GA6619 1 Mounting Arm
9 G10463 2 Cotter Pin, ¼" x 1½"
10 G10171
G10232
G10106 4
4
4 Hex Head Cap Screw, 5∕16"-18 x 1¼"
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
11 GA6620 2 Bracket
12 GA6618 2 Mount
13 G10303
G11386
G10232
G10106 2
2
2
2 Carriage Bolt, 5∕16"-18 x 1"
Flat Washer, 5∕16" SAE
Lock Washer, 5∕16"
Hex Nut, 5∕16"-18
14 G10107 3 Lock Nut, ⅝"-11
15 GD1109 2 Bushing, 41∕64" I.D. x ⅞" O.D. x ¼" Long
16 GD9290 2 Disc Blade, 8"
17 G10018
G10109 7
7 Hex Head Cap Screw, 5∕16"-18 x ⅝"
Lock Nut, 5∕16"-18, Grade 8
18 G10152 1 Hex Head Cap Screw, ⅝"-11 x 9"
19 GD3180-12 2 Sleeve, ⅝" I.D. x ⅞" O.D. x 2⅞" Long
20 GD9562 2 Half Wheel
21 GA6171 1 Bearing
22 GD9305 1 Tire
23 GA2014 2 Bearing
24 GD10473 2 Bearing Housing
25 G10427 12 Rivet, ¼" x ½"
26 G10006 2 Hex Head Cap Screw, ⅝"-11 x 2¼"
27 GD11845 2 Dust Cap
A GA6733 - Single Press Wheel Complete W/Bearing (Items 17 and 20-22)
B GA6801 - Covering Disc Blade Complete W/Bearing (Items 16 and 23-25)
TM
Model 3000 M0188-02
Rev. 6/11 P8
