7 Object dictionary
0x6127 0x01 float RW Al Scaling
Offset 1 Scaling offset ex-factory: 0
e.g. 0.0, to show
pressure not as
0 — 100% but as
0 —10 bar; or e.g.
32, to show tempe-
rature not in °C but
in °F.
0x02 float RW Al Scaling
Offset 2 as subindex 0x01, for
devices with 2 sensors
0x6130 0x01 float RO Al Input PV
float 1 Process value as float
(for readout via SDO)
0x02 float RO Al Input PV
float 2 as subindex 0x01, for
devices with 2 sensors
0x6132 0x01 UINT8 RW Al Decimal
Digits 1 Decimal places for
fixed-point representa-
tion as INT 32 as in
PDO 0 — 3
ex-factory: 1
Example, pressure:
0 => 0 — 100 =
0 — 100%
1 => 0 — 1000 =
0 — 100.0%
2 => 0 — 10000 =
0 — 100.00%
Example, temp.:
0 => 19 = 19°C
1 => 197 = 19.7°C
2 => 1973 = 19.73°C
0x02 UINT8 RW Al Decimal
Digits 2 as subindex 0x01, for
devices with 2 sensors
0x6133 0x01 float RW Al Interrupt
Delta Input
PV1 Delta value for event-
controlled PDO trans-
mission ex-factory: 1.0
(0 = inactive)
0x02 float RW Al Interrupt
Delta Input
PV2 as subindex 0x01, for
devices with 2 sensors
0x6148 0x01 float RW Al Span Begin
1 Start of range
monitoring ex-factory: 0
(P sensor)
ex-factory: -50
(T sensor)
0x02 float RW Al Span Begin
2 as subindex 0x01, for
devices with 2 sensors
0x6149 0x01 float RW Al Span End 1 End of range monitoring ex-factory: 100
(P sensor)
ex-factory: 450
(T sensor)
0x02 float RW Al Span End 2 as subindex 0x01, for
devices with 2 sensors
