25
7 Object dictionary
7.1 Overview
The entire object dictionary is available as an EDS file, thereby enabling all
CANopen-compatible configuration programs to be used for installation and
parameterization. For this reason, JUMO does not supply a setup program for
these devices.
The most important setting parameters are summerized below, together with
their possible values.
All objects can be read, or written, with SDO telegrams. This object dictionary
is valid for all CANtrans variants. Depending on the device, some objects have
1 or 2 subindices. Accordingly, the CANtrans p, for example, only has the
subindex 1 = pressure channel, whereas the CANtrans pT has the subindex 1
= pressure channel and the subindex 2 = temperature channel.
For all device types, the corresponding EDS file is downloadable free of
charge from the JUMO home page => www.jumo.net.
Index Sub-
index Format Access Name Description Value
0x1017 - UINT16 RW Heartbeat
Producer Time Time for cyclic trans-
mission of a “sign of
life” 0 — 65535 msec
0 = inactive
ex-factory: 0
0x100C - UINT16 RW Guard Time Time factor for monitor-
ing Node Guarding 0 — 65535 msec
0 = inactive
ex-factory: 0
0x100D - UINT8 RW Live Time
Factor Multiplier for monitor-
ing Node Guarding 0 — 255
0 = inactive
ex-factory: 0
