4 Installation
28
4.1.1
Turning the LCD display
The device LCD display can be turned through 180°. (Either via the setting on the device or the
optional setup program).
This will facilitate reading when, for example, the device is installed turned through 180°.
Chapter 6.17 "Setting the display alignment (D.Dir)", page 63
4.1.2
Turning the display case
The display case of the device can be turned to the LH or RH side through
±
160° using the
supplied combination tool (1).
(1)
Combination tool
