2 Identifying the instrument version

2.1

Rating plate

Position

The rating plate is glued laterally to the transmitter.
The factory set probe ID is additionally stated on a sign fitted on top of the transmitter.

Contents

The rating plate contains important information. This includes:

Device type

Compare the specifications on the rating plate to your order documents. The supplied device
version can be identified using the type key in Chapter 2.2 "Order details", page 10.

Sales No. (VARTN)

The Sales No. provides an unambiguous definition of an article from the catalog. It is important
for communication between the sales department and the customer.

Fabrication No. (F-No.)

The fabrication number (F-No.) indicates, among others, the production date (year/week) and
the hardware version number.

Production date

Example: F-No. = 0070033801210220006
The figures concerned are in positions 12, 13, 14, 15 (from the left).
Thus the device was produced in the 22nd calendar week in 2010.

Probe ID

The probe ID is factory set. It must be entered and activated on the receiver to establish com-
munication between the probe and receiver. The probe ID can be changed to customer specific
requirements using the setup program. The user must exclude that several probes with identi-
cal probe IDs are active.

Transmission frequency

The transmission frequency identifies the frequency and frequency band used by the device
for transmission. In the 868 MHz band (Europe), the transmission is carried out at 868.4 MHz.

Description

Designation on the rating
plate

Example

Device type

Type

707060/8-10/000

Sales No.

VARTN

70/XXXXXXXX

Fabrication No.

F-No

0070033801210220006

Voltage supply

DC 3.6 V

Probe ID

123

Transmission frequency

868.4 MHz
