7 Setup program

34

7.4.4

Transmitting new parameters to the probe

How to proceed:

7.5

Parameters overview

Step

Activity

1

In the "Data transfer" menu select the "Data transfer to device" function.
The current parameters are transmitted to the probe.

2

Finish the communication between setup program and probe in the "Data transfer"
menu using the "Disconnect connection" function.

Parameters

Factory setting

Value range/Selection

Probe ID

inactive

1 ... 99999

Transmission interval 15 s

1 ... 3600 s

Transmission fre-
quency

868.4 MHz

868.4 MHz
Display only, cannot be edited!

Probe type

RTD temperature
probe

RTD temperature probe
Thermocouple
Resistance/potentiometer
Resistance transmitter
Voltage

Sensor

Pt100

Depending on the probe type,
Pt100 DIN EN 60751 -200 ... +600 °C

Connection type

3-wire circuit

3-wire circuit,
2-wire circuit

Lead resistance R

l

0 Ohm

0 to 22 Ohm
Only with 2-wire circuit!

Resistance R

X

10000 Ohm

5 to 10000 Ohm
Only for resistance/potentiometer sensor-
type!

Resistance R

0

0 Ohm

0 to 4000 Ohm
Only for resistance/potentiometer
sensor type!
Only for linearization 0 to 100 %

Resistance R

A

0 Ohm

0 to 10000 Ohm
Only for resistance transmitter
sensor type!

Resistance R

S

10000 Ohm

5 to 10000 Ohm
Only for resistance transmitter
sensor type!

Resistance R

E

0 Ohm

0 to 10000 Ohm
Only for resistance transmitter
sensor type!
