5 Installation
5.1
Information about fastening, securing and arrangement
TIP!
Install the antenna-battery case vertically to the top and, if possible, with free view to the re-
ceiver antenna.
TIP!
Never cover or coat the antenna-battery case with metallic objects. Otherwise, the probe
range is impaired.
TIP!
For optimum probe function ensure a minimum spacing of 200 mm between the probes.
