8 Supplement

38

Thermocouples

Resistance / potentiometer

Designation

Standard

Measuring range

Measuring accuracy

a

Fe-CuNi „L“

DIN 43710

-200 to +900 °C

± 0.1 %

Fe-CuNi „J“

DIN EN 60584

-210 to +1200 °C

± 0.1 % as of -100 °C

Cu-CuNi „U“

DIN 43710

-200 to +600 °C

± 0.1 % as of -100 °C

Cu-CuNi T

DIN EN 60584

-270 to +400 °C

± 0.1 % as of -150 °C

NiCr-Ni K

DIN EN 60584

-270 to +1372 °C

± 0.1 % as of -80 °C

NiCr-CuNi „E“

DIN EN 60584

-270 to +1000 °C

± 0.1 % as of -80 °C

NiCrSi-NiSi „N“

DIN EN 60584

-270 to +1300 °C

± 0.1 % as of -80 °C

Pt10Rh-Pt „S“

DIN EN 60584

-50 to +1768 °C

± 0.15 % as of 20 °C

Pt13Rh-Pt „R“

DIN EN 60584

-50 to +1768 °C

± 0.15 % as of 50 °C

Pt30Rh-Pt6Rh „B“

DIN EN 60584

0 to 1820 °C

± 0.15 % as of 400 °C

W5Re-W26Re „C“

0 to 2320 °C

± 0.15 %

W3Re-W25Re „D“

0 to 2495 °C

± 0.25 %

W3Re-W26Re

0 to 2400 °C

± 0.15 %

Chromel-Copel

-200 to +800 °C

± 0.1 % as of -80 °C

Chromel-Alumel

-200 to +1372 °C

± 0.1 % as of -80 °C

PLII (Platinel II)

0 to 1395 °C

± 0.15 %

MoRe5-MoRe41

0 to 2000 °C

± 0.2 %

Cold junction

Pt1000 internal

Cold junction accuracy

±

1 K

a

All accuracies given in % refer to the maximum measuring range

Designation

Measuring range

Measuring accuracy

a

Resistance / potentiometer
Linearization: 0 to 100 %

>

50

Ω

to

400

Ω

>

400

Ω

to

4000

Ω

>

4000

Ω

to

10000

Ω

±

400 m

Ω

±

4

Ω

±

10

Ω

Resistance / potentiometer
Linearization: Resistance in

Ω

> 50

Ω

to

10000

Ω

±

0.1 %

Connection type

2-wire or 3-wire circuit

Lead compensation

Not required for 3-wire circuit (admissible max.11

Ω

per line).

Max. configurable lead-wire resistance for 2-wire circuit: 22

Ω

.

a

All accuracies given in % refer to the maximum measuring range
