7 Setup program

30

TTL/RS232

For the setup via the TTL/RS232 converter, establish the following connections:

(1)

Laptop/PC

(3)

Adapter socket, 4-pin

(2)

RS232 connector

(4)

Probe interface

Step

Activity

1

Insert the RS232 connector (2) into the laptop/PC (1).

2

Connect the adapter socket, 4-pin, (3) to the probe interface (4).

(1)

(2)

(3)

(4)

TIP!
For probe configuration, ensure that the probe is connected to the voltage supply of the an-
tenna-battery case.
