9 Appendix
9.1 Technical data
9.1.1 Analog inputs
General information
Thermocouples
Number 4
A/D converter
Dynamic resolution up to 16 bit
Designation Standard Measuring range Measuring accu-
racy
1
Ambient
temperature influ-
ence
Fe-CuNi “L” -200 to +900 °C ≤ 0.1 % from -100 °C 300 ppm/K
Fe-CuNi “J” DIN EN 60584 -200 to +1200°C ≤ 0.1 % from -100 °C 300 ppm/K
Cu-CuNi “U” -200 to +600 °C ≤ 0.1 % from -130 °C 300 ppm/K
Cu-CuNi “T” DIN EN 60584 -200 to +400 °C ≤ 0.1 % from -150 °C 300 ppm/K
NiCr-Ni “K” DIN EN 60584 -200 to +1372 °C ≤ 0.1 % from -80 °C 300 ppm/K
NiCr-CuNi „E“ DIN EN 60584 -200 to +1000 °C ≤ 0.1 % from -80 °C 300 ppm/K
NiCrSi-NiSi “N” DIN EN 60584 -100 to +1300 °C ≤ 0.1 % from -80 °C 300 ppm/K
Pt10Rh-Pt “S” DIN EN 60584 -50 to 1768 °C ≤ 0.15 % from 20 °C 300 ppm/K
Pt13Rh-Pt “R” DIN EN 60584 -50 to 1768 °C ≤ 0.15 % from 20 °C 300 ppm/K
Pt30Rh-Pt6Rh “B” DIN EN 60584 0 to 1820 °C ≤ 0.15 % from 400 °C 300 ppm/K
W5Re-W26Re „C“ 0 to 2320 °C ≤ 0.15 % from 500 °C 300 ppm/K
W3Re-W25Re “D” 0 to 2495 °C ≤ 0.15 % from 500 °C 300 ppm/K
W3Re-W26Re 0 to 2400 °C ≤ 0.15 % from 500 °C 300 ppm/K
Chromel-Copel GOST 8.585-
2001 -200 to +800 °C ≤ 0.15 % from -80 °C 300 ppm/K
Chromel-Alumel GOST 8.585-
2001
-200 to +1372 °C ≤ 0.10 % from -80 °C 300 ppm/K
PLII (Platinel II) 0 to 1395 °C ≤ 0.10 % from -80 °C 300 ppm/K
Linear 0 to 75 mV ≤ 0.1 % 300 ppm/K
Cold junction Pt100 internal
Cold junction accuracy ± 1 K
1
The accuracy values refer to the maximum measuring range. Smaller measuring ranges lead to reduced lineariza-
tion accuracy.
