7 Configuration – in setup program only

58

Displaying linearization on a graphic ("Display graphic" button)

Use this button to create a graphic of the linearization.
The graphic includes the characteristic lines for both types of linearization where applicable,
namely the formula and the grid points (table).
The displayed graphic range is initially defined by the "Measuring range start" and the "Mea-
suring range end" values (y-values). Within the graphic, the range can be changed temporarily
by entering other x-values.

TIP!
A linearized value beyond the co-domain limits causes an overange or an underrange (out-of-
range).
