35

6 Configuration

Linearization

Available options and factory settings depend on the measuring probe selected

Linear

Pt50

GOST 6651-94

Pt100

DIN EN 60751

Pt500

DIN EN 60751

Pt1000

DIN EN 60751

Pt100J

JIS 1604

Pt100G

GOST 6651-94

KTY

Type KTY11-6

Cu50

GOST 6651-94

Cu100

GOST 6651-94

Ni100

DIN EN 60751

NiCr-CuNi_E

DIN EN 60584

Cu-CuNi_T

DIN EN 60584

Fe-CuNi_J

DIN EN 60584

Cu_CuNi_U

Fe-CuNi_L

NiCr-Ni_K

DIN EN 60584

Pt10Rh-Pt_S

DIN EN 60584

Pt13Rh-Pt_R

DIN EN 60584

Pt30Rh-Pt6Rh_B

DIN EN 60584

NiCrSi-NiSi_N

DIN EN 60584

W5Re-W26Re_C

W3Re-W25Re_D

W3Re-W26Re

Chromel-Copel

GOST 8.585-2001

Chromel-Alumel

GOST 8.585-2001

Platinel II

Customer-specific

Customer-specific linearization using
grid points (pairs of values) or 4th order
polynomial

Measuring range
start

Factory setting depends on sensor and linearization.

-99999 to +99999

Start value of the measuring range (for
resistance transmitter, standard signal,
and potentiometer) to detect out of
range

Measuring range
end

Factory setting depends on sensor and linearization.

-99999 to +99999

End value of measuring range (see
above) to detect out of range

Parameter

Selection/settings

Description

?

?

?
