JULABO FC600-T Recirculating cooler User Manual
Page 9

Recirculating coolers
9
(with T-pump)
FCW2500T
Working temperature range
°C -25 ... 80
Cooling capacity
°C +20 +10 +5 0 -10 -20
(water-glycol)
kW 2.5 2.0 1.8 1.5 0.8 0.25
Refrigerant
R404A
Heater capacity
kW 1.2
Pump capacity:
Pressure max.
bar 3.5
Flow rate max.
Lpm 28
Pump connections
M16x1
Noise level, 1 m distance
dBA 70
Filling volume
l 8 ... 11
Dimensions (WxLxH)
cm 46 x 61 x 49
Shipping weight
kg 74
Mains power connection
V/Hz 230/60
Total power consumption
W 2800
(with S-pump)
FC1200S
FCW1200S
Working temperature range
°C -15 ... 80 -15 ... 80
Cooling capacity
°C
20 10 5 -10
(water-glycol)
kW
0.12 0.85 0.65 0.26
Refrigerant
R134a
Heater capacity
kW
1.2
Pump capacity:
Pressure max.
bar
1.2
Flow rate max.
l/min
22 / 15
with tubing connections
mm dia.
13.5 / 9.5
Pump connections
M16x1
Noise level, 1 m distance
dBA 57
53
Filling volume
l
8 ... 11
Dimensions (WxLxH)
cm
46 x 61 x 49
Ambient temperature
°C
5 ... 40
Shipping weight
kg 66
68
Mains power connection
V/Hz
208-230/60 or 230/50
Total power consumption
W
2800
All data have been determined at
mains voltage: 230 V / 50 Hz
ambient temperature: 20 °C
bath liquid: water-glycol
