Operating controls and functional elements
18
Rear
12.1
Pump connector: Feed
12.2
Pump connector: Return
13.
Overflow port for bath tank
14.
Connectors for solenoid valves
15.
Mains power cable with plug
!
16.2
12.1
16.1
12.2
13.
14.
Only for water cooled models:
16.1
Cooling water OUTLET
16.2
Cooling water INLET
