JULABO FC600-T Recirculating cooler User Manual
Page 11

Recirculating coolers
11
(with Ju-pump)
FC1200 -T
Working temperature range
°C -20 ... 80
Cooling capacity
°C 20 10 5 -10
(water-glycol)
kW 1.3 0.95 0.75 0.37
Refrigerant
R134a
Heater capacity
kW 1.2
Pump capacity:
Pressure max.
bar 0.5
Flow rate max.
Lpm 20 / 14
with tubing connections
mm dia. 13,5/9,5
Pump connections
M16x1
Noise level, 1 m distance
dBA 53
Filling volume
l 8 ... 11
Dimensions (WxLxH)
cm 46 x 61 x 49
Ambient temperature
°C 5 ... 40
Shipping weight
kg 65
Mains power connection
V/Hz 208-230/60 or 230/50
Total power consumption
W 2300
(with Ju-pump)
FC1600 -T
Working temperature range
°C -20 ... 80
Cooling capacity
°C 20 10 5 -10
(water-glycol)
kW 1.65 1.25 1.0 0.47
Refrigerant
R134a
Heater capacity
kW 1.2
Pump capacity:
Pressure max.
bar 0.5
Flow rate max.
Lpm 20 / 14
with tubing connections
mm dia. 13,5/9,5
Pump connections
M16x1
Noise level, 1 m distance
dBA 53
Filling volume
l 8 ... 11
Dimensions (WxLxH)
cm 46 x 61 x 49
Ambient temperature
°C 5 ... 40
Shipping weight
kg 65
Mains power connection
V/Hz 208-230/60 or 230/50
Total power consumption
W 2400
All data have been determined at
rated voltage and frequency
ambient temperature: 20 °C
bath liquid: water-glycol
