JULABO FC600-T Recirculating cooler User Manual
Page 10

Operator responsibility – Safety instructions
10
(with S-pump)
FC1600S
FCW1600S
Working temperature range
°C -15 ... 80 -15 ... 80
Cooling capacity
°C
20 10 5 -10
(water-glycol)
kW
1.55 1.15 0.9 0.36
Refrigerant
R134a
Heater capacity
kW
1.2
Pump capacity:
Pressure max.
bar
1.2
Flow rate max.
l/min
22 / 15
with tubing connections
mm dia.
13.5 / 9.5
Pump connections
M16x1
Noise level, 1 m distance
dBA 57
53
Filling volume
l
8 ... 11
Dimensions (WxLxH)
cm
46 x 61 x 49
Ambient temperature
°C
5 ... 40
Shipping weight
kg 66
68
Mains power connection
V/Hz
208-230/60 or 230/50
Total power consumption
W
2900
(with Ju-pump)
FC600 -T
Working temperature range
°C -20 ... 80
Cooling capacity
°C 20 10 5 -10
(water-glycol)
kW 0.6 0.47 0.4 0.21
Refrigerant
R134a
Heater capacity
kW 1.2
Pump capacity:
Pressure max.
bar 0.5
Flow rate max.
Lpm 20 / 14
with tubing connections
mm dia 13,5/9,5
Pump connections
M16x1
Noise level, 1 m distance
dBA 51
Filling volume
l 6 ... 8
Dimensions (WxLxH)
cm 46 x 61 x 49
Ambient temperature
°C 5 ... 40
Shipping weight
kg 48
Mains power connection
V/Hz 208-230/60 or 230/50
Total power consumption
W 2000
All data have been determined at
rated voltage and frequency
ambient temperature: 20 °C
bath liquid: water-glycol
