40
tina03e1-b (2004-02) BPG400 v1.om
The following table lists all permissible commands of the RS485 host and the cor-
responding responses of a BPG400 SR during data transfer.
Depending on the operation mode selected (BPG or RIG mode) the BPG400-SR
responses may differ. Syntax errors will produce an error message.
For each command listed, a programming example is given in the last column
where:
T: Command data transmitted by the host
R: Data received by the host (from BPG400-SR), in BPG and RIG mode
R
BPG
: Data received by the host (from BPG400-SR), only in BPG mode
R
RIG
: Data received by the host (from BPG400-SR), only in RIG mode
Host Command Host
Command syntax BPG mode
Response syntax
RIG mode
Response syntax
Programming example and remarks
Read pressure
measured value #aaRD CR *aa_x.xxEsyy CR → BPG mode T: #02RD CR
R: *02_5.36E–04 CR
R
RIG
: *02_9.99E+09 CR
If gauge is switched off and during the first 3
seconds after gauge is switched on.
Read status #aaRS CR *aa_status CR → BPG mode T: #02RS CR
R
BPG
: *02_BPG_ST_5 CR
R
RIG
: *02_00_ST_OK CR
Set address (offset) #aaSAoo CR *aa_PROGM_OK CR → BPG mode T: #02A3_CR
R *02_PROGM_OK CR
New address becomes effective after power is
cycled or a reset command is executed.
If the user sets the offset address to a value so
that the operating device address would be
>0x3F
Hex
, the offset address is set to "0" by the
device itself.
Set pressure unit #aaSUunit CR *aa_PROGM_OK CR Error message T: #02SUPASCAL CR
R
BPG
: *02_PROGM_OK CR
New unit becomes effective after power is
cycled or a reset command is executed.
R
RIG
: ?02_SYNTX_ER CR
Read pressure unit #aaRU CR *aa_unit CR Error message T: #02RU CR
R
BPG
: *02_PASCAL CR
R
RIG
: ?02_SYNTX_ER CR
Set filament #aaSFn CR For future use *aa_PROGM_OK CR T: #02SF2 CR
R: *02_PROGM_OK CR
Set overpressure #aaSOx.xxEsyy CR For future use *aa_PROGM_OK CR T: #02SO5.00E–02 CR
R: *02_PROGM_OK CR
Set degas off #aaDG0 CR *aa_PROGM_OK CR → BPG mode T: #02DG0 CR
R: *02_PROGM_OK CR
Set degas on #aaDG1 CR *aa_PROGM_OK CR → BPG mode T: #02DG1 CR
R: *02_PROGM_OK CR
When the gauge is switched off, a degas on
command will produce an error message:
R: ?02_COMM_ERR CR
If pressure is >7.20E–06 mbar, the degas on
command is disabled
Read emission #aaSES CR *aa_xxFA_EM CR → BPG mode T: #02SES CR
R: *02_
_20MA_EM CR
Read version #aaVER CR *aa_VERv.vv CR → BPG mode T: #02VER CR
R: *02_VER_1.04 CR
Table continued on following page
4.9.3.2 Commands and
Responses
