In all communications with INFICON, please specify the information on the product
nameplate. For convenient reference copy that information into the space provided
below.
Model:
PN:
SN:
V W
INFICON AG, LI-9496 Balzers
This document applies to products with the following part numbers:
BPG400 (without display)
353-500 (vacuum connection DN 25 ISO-KF)
353-502 (vacuum connection DN 40 CF-R)
BPG400 (with display)
353-501 (vacuum connection DN 25 ISO-KF)
353-503 (vacuum connection DN 40 CF-R)
BPG400-SD (with DeviceNet interface and switching functions)
353-507 (vacuum connection DN 25 ISO-KF)
353-508 (vacuum connection DN 40 CF-R)
BPG400-SP (with Profibus interface and switching functions)
353-505 (vacuum connection DN 25 ISO-KF)
353-506 (vacuum connection DN 40 CF-R)
BPG400-SR (with RS485 interface and switching functions)
353-509 (vacuum connection DN 25 ISO-KF)
353-513 (vacuum connection DN 40 CF-R)
The part number (PN) can be taken from the product nameplate.
If not indicated otherwise in the legends, the illustrations in this docu-
ment correspond to gauge with part number 353-500. They apply to the
other gauges by analogy.
All BPG400 versions are shipped with an instruction sheet ( → [8]). BPG400-SD,
BPG400-SP and BPG400-SR come with a supplementary instruction sheet de-
scribing the fieldbus interfaces and the switching functions (
→ [9]).
We reserve the right to make technical changes without prior notice.
The BPG400 gauges have been designed for vacuum measurement of non-flam-
mable gases and gas mixtures in a pressure range of 5×10
-10 … 1000 mbar.
The gauges can be operated in connection with the INFICON Vacuum Gauge
Controller VGC103 or VGC40x or with other control devices.
