50
tira85e1 (2013-06) PxG55x.cp
Device Error Mask Module 1: Mask bits for 0xF383:02 and 0xF393:02.
Manufacturer Error Mask: Mask bits for 0xF384:01 and 0xF394:01.
Index SI DataType NV Access PM Name
F640 0x01 BOOL RO tx Combination Gauge
Reading Valid
0x02 BOOL RO tx Combination Gauge
Overrange Exceeded
0x03 BOOL RO tx Combination Gauge
Underrange Exceeded
0x11 REAL RO tx Combination Gauge Active
Value
0x12 UINT RO tx Combination Gauge Active
Sensor Number
Identifies whether the complete vacuum pressure gauge (with several measuring
principles) is out of its absolute overrange or absolute underrange, or in any other
failure condition.
If the bit “Overrange” is set, all instances of the gauge are in an overrange
condition.
If the bit “Underrange” is set, all instances of the gauge are in an underrange
condition
The value copied from the measurement value of the active measuring instance
used for the Input PDO.
Identifies the object instance that is providing the measurement value, the latter of
which is copied into the Active Value parameter for all Input PDO’s.
Index SI DataType NV Access PM Name
F641 0x01 UDINT RO tx Trip Point Output All
Instance
Status of Trip Point instances.
Trip Point Output All Instance
Bit 0
Bit 1
Bit 2
Bit 3
…
Bit 30
Bit 31
Status High Trip (I 0x600E, SI 0x01)
Status Low Trip (I 0x600E S,I 0x02)
Status High Trip (I 0x600F, SI 0x01)
Status Low Trip (I 0x600F, SI 0x02)
…
Status High Trip (I 0x608F, SI 0x01)
Status Low Trip (I 0x608F, SI 0x02)
Subindex 0x02
Subindex 0x01 (F3A4)
4.15 Gauge General
4.15.1 Combination Gauge
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x11
Subindex 0x12
4.15.2 Trip Point Output All
Subindex 0x01
