42
tira85e1 (2013-06) PxG55x.cp
Active Device Warning Details(Index F381)
Bit 0
0
Bit 1 Electronics exception
Bit 2…31 0
Active Device Warning Details(Index F381)
Bit 0
0
Bit 1 Electronics exception
Bit 2…31 0
Active Manufacturer Warning Details (Index F382)
Bit 0
Internal Communication Exception (between
EtherCAT-Protocol and Device-Application)
Bit 1…31 0
The "active device warning details" parameter describes the warning state of the
complete device.
Index SI DataType NV Access PM Name
F381 0x01 UDINT RO tx Active Device Warning
Details Device
0x02 UDINT RO tx Active Device Warning
Details Module 1
0x03 UDINT RO tx Active Device Warning
Details Module 2
F382 0x01 UDINT RO tx Active Manufacturer
Warning Details
Active Device Warning Details(Index F381)
Bit 0…2
0
Bit 3 EEPROM exception
Bit 4…31 0
Active Device Warning Details(Index F381)
Bit 0
0
Bit 1 Electronics exception
Bit 2…31 0
Active Device Warning Details(Index F381)
Bit 0
0
Bit 1 Electronics exception
Bit 2…31 0
Active Manufacturer Warning Details (Index F382)
Bit 0
Internal Communication Exception (between
EtherCAT-Protocol and Device-Application)
Bit 1…31 0
Subindex 0x03 (Piezo)
Subindex 0x04 (Pirani)
Subindex 0x01
4.14.3 PCG without ATM,
Active Device Warning
Details
Subindex 0x01
Subindex 0x02 (CDG)
Subindex 0x03 (Pirani)
Subindex 0x01
