INFICON PSG55x ATM to Medium Vacuum Gauge (EtherCAT) - Manual (Page 45)

tira85e1 (2013-06) PxG55x.cp
45
The "active device error details" parameter describes the error state of the
complete device.
Index SI DataType NV Access PM Name
F383 0x01 UDINT RO tx Active Device Error Details
Device
0x02 UDINT RO tx Active Device Error Details
Module 1
F384 0x01 UDINT RO tx Active Manufacturer Error
Details
Active Device Error Details (Index F383)
Bit 0…2
0
Bit 3 EEPROM exception
Bit 4…31 0
Active Device Error Details (Index F383)
Bit 0
Sensor Failure
Bit 1 Electronics exception
Bit 2…31 0
Active Manufacturer Error Details (Index F384)
Bit 0
Internal Communication Exception (between
EtherCAT-Protocol and Device-Application)
Bit 1…31 0
Index SI DataType NV Access PM Name
F390 USINT RO tx Latched Exceptions Status
F391 0x01 UDINT RO tx Latched Device Warning
Details Device
0x02 UDINT RO tx Latched Device Warning
Details Module 1
0x03 UDINT RO tx Latched Device Warning
Details Module 2
0x04 UDINT RO tx Latched Device Warning
Detail Module 3
F392 0x01 UDINT RO tx Latched Manufacturer
Warning Details
Latched version of 0xF380.
Latched Device Warning Details Device: Latched version of 0xF381:01.
Latched Device Warning Details Module 1: Latched version of 0xF381:02.
Latched Device Warning Details Module 2: Latched version of 0xF381:03.
Latched Device Warning Details Module 3: Latched version of 0xF381:04.
Latched Manufacturer Warning Details: Latched version of 0xF382:01.
4.14.7 PSG Active Device
Error Details
Subindex 0x01
Subindex 0x02 (Pirani)
Subindex 0x01
4.14.8 PCG with ATM Latched
Device Warning Details
Latched Exceptions Status
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x04
Subindex 0x01 (F392)
