INFICON PSG55x ATM to Medium Vacuum Gauge (EtherCAT) - Manual (Page 14)

14
tira85e1 (2013-06) PxG55x.cp
Index SI DataType NV Access PM Name
1A00
or 1A02
or 1A04 PM RW TxPDO Transmit PDO
Mapping
0x01 BIT Reading Valid
0x02 BIT Overrange Exceeded
0x03 BIT Underrange Exceeded
0x04 BIT Padding Bits 1 (5 bit)
0x05 REAL Sensor Value
0x06 UDINT Trip Point Output All
Instance
1A01
or 1A03
or 1A05 PM RW TxPDO Transmit PDO
Mapping, User Mapping
Index SI DataType NV Access PM Name
1A00
or 1A02
or 1A04 PM RW TxPDO Transmit PDO
Mapping
0x01 BIT Combination Gauge
Reading Valid
0x02 BIT Combination Gauge
Overrange Exceeded
0x03 BIT Combination Gauge
Underrange Exceeded
0x04 BIT Padding Bits 1 (5 bit)
0x05 REAL Combination Gauge Active
Value
0x06 UDINT Trip Point Output ALL
Instance
1A01
or 1A03
or 1A05 PM RW TxPDO Transmit PDO
Mapping, User Mapping
1C00 0x01
0x02
0x03
0x04
BYTE RW Sync Manager Type
1C12 /
1C13 0x01
0x02
0x03
0x04 UINT RW Sync Manager PDO
Assignment
1C32 /
1C33 0x01
-
0x20 RW Sync Manager Parameter
4.2.1 TxPDO’s PSG
4.2.2 TxPDO’s PCG
