Active Device Error Details (Index F383)
Bit 0
Sensor Failure
Bit 1 Electronics exception
Bit 2…31 0
Active Manufacturer Error Details (Index F384)
Bit 0
Internal Communication Exception (between
EtherCAT-Protocol and Device-Application)
Bit 1…31 0
The "active device error details" parameter describes the error state of the
complete device.
Index SI DataType NV Access PM Name
F383 0x01 UDINT RO tx Active Device Error Details
Device
0x02 UDINT RO tx Active Device Error Details
Module 1
0x03 UDINT RO tx Active Device Error Details
Module 2
F384 0x01 UDINT RO tx Active Manufacturer Error
Details
Active Device Error Details (Index F383)
Bit 0…2
0
Bit 3 EEPROM exception
Bit 4…31 0
Active Device Error Details (Index F383)
Bit 0
Diaphragm Failure
Bit 1 Electronics failure
Bit 2…32 0
Active Device Error Details (Index F383)
Bit 0
Sensor Failure
Bit 1 Electronics exception
Bit 2…31 0
Active Manufacturer Error Details (Index F384)
Bit 0
Internal Communication Exception (between
EtherCAT-Protocol and Device-Application)
Bit 1…31 0
Subindex 0x04 (Pirani)
Subindex 0x01
4.14.6 PCG without ATM,
Active Device Error
Details
Subindex 0x01
Subindex 0x02 (CDG)
Subindex 0x03 (Pirani)
Subindex 0x01
