Page 48
48
tira85e1 (2013-06) PxG55x.cp
Index
SI
DataType
NV Access PM Name
F3A1
0x01 UDINT
x
RW
Device Warning Mask
Device
0x02 UDINT
x
RW
Device Warning Mask
Module 1
0x03 UDINT
x
RW
Device Warning Mask
Module 2
0x04 UDINT
X
RW
Device Warning Mask
Module 3
F3A2 0x01
UDINT x RW Manufacturer
Warning
Mask
Device Warning Mask Device: Mask bits for 0xF381:01 and 0xF391:01.
Device Warning Mask Module 1: Mask bits for 0xF381:02 and 0xF391:02.
Device Warning Mask Module 2: Mask bits for 0xF381:03 and 0xF391:03.
Device Warning Mask Module 3: Mask bits for 0xF381:03 and 0xF391:04.
Manufacturer Warning Mask: Mask bits for 0xF382:01 and 0xF392:01.
Index
SI
DataType
NV Access PM Name
F3A1
0x01 UDINT
x
RW
Device Warning Mask
Device
0x02 UDINT
x
RW
Device Warning Mask
Module 1
0x03 UDINT
x
RW
Device Warning Mask
Module 2
F3A2 0x01
UDINT x RW Manufacturer
Warning
Mask
Device Warning Mask Device: Mask bits for 0xF381:01 and 0xF391:01.
Device Warning Mask Module 1: Mask bits for 0xF381:02 and 0xF391:02.
Device Warning Mask Module 2: Mask bits for 0xF381:03 and 0xF391:03.
Manufacturer Warning Mask: Mask bits for 0xF382:01 and 0xF392:01.
Index
SI
DataType
NV Access PM Name
F3A1
0x01 UDINT
x
RW
Device Warning Mask
Device
0x02 UDINT
x
RW
Device Warning Mask
Module 1
F3A2 0x01
UDINT x RW Manufacturer
Warning
Mask
Device Warning Mask Device: Mask bits for 0xF381:01 and 0xF391:01.
4.14.14 PCG with ATM Device
Warning Mask
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x04
Subindex 0x01 (F3A2)
4.14.15 PCG without ATM,
Device Warning Mask
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x01 (F3A2)
4.14.16 Device Warning Mask
Subindex 0x01
