1 Technical
Data
Further technical data
→ [1], [2].
The voltage for the gauge equipped with the DeviceNet interface is supplied via the
DeviceNet cable.
Fieldbus name
DeviceNet
Standard applied
→ [4]
Communication protocol, data format
→ [4]
Interface, physical
CAN bus
Data rate (adjustable via "RATE"
switch)
125 kBaud
250 kBaud
500 kBaud (default)
"P" (125 kBaud, 250 kBaud, 500 kBaud
programmable via DeviceNet
Node address (MAC ID)
(Adjustable via "ADDRESS", "MSD",
"LSD" switches)
0 … 63
dec
(default = 63
dec
)
"P" (0 … 63 programmable via
DeviceNet)
DeviceNet connector
Micro-Style, 5-pin, male
Cable
Shielded, special DeviceNet cable,
5 conductors
(
→ 7 and [3])
Cable length, system wiring
according to DeviceNet specifications
(
→ [3], [4])
DeviceNet interface
