Service
Code
Service Name
Description of Service
32
h
User Atmosphere
Adjust
Performs an Atmosphere Adjust: Piezo will be
adjusted to the Capacitance Diaphragm
Gauge.
Parameter
Data Type
Semantics of Values
User Atmosphere Adjust
parameter
BOOL
0 = disable adjustment
1 = Execute one User
Atmosphere Adjust
To perform the User Atmosphere Adjust Request the flange input has to be in the
same environment as the electronic part and then start the User Atmosphere
Adjust Service with the value 1.
Following is the instance 1 with the subclass extension of the heat transfer mano-
meter part of the gauge (valid for PSG55x).
Attribute
ID
Access rule NV/
V
Name
DeviceNet
data type
Description of attribute
Semantics of values
3
→
"Semantics"
NV Data type USINT
Determines the data type
of value and all related
attributes as specified in
this table.
→ "Semantics" section below
[default] = INT
4
→
"Semantics"
NV Data units UINT
Determines the units con-
text of value and all related
attributes.
[default] = Counts
5 Get
V
Reading
valid
BOOL
Indicates that the value
attribute contains a valid
value.
0 = invalid
1 = valid
(invalid: e.g., sensor is out of its
specified range)
6
Get
V Value
INT or REAL
Analog input value.
The corrected, converted, calibrated
final value of the sensor.
→ "Semantics" section
7
Get
V Status
BYTE
Alarm and warning state of
this object instance.
= 0
10
Get
NV Full scale
INT or REAL
The value of full scale for
the sensor.
[default] = maximum allowable value
for the data type
25
Set
NV Safe state USINT
Specifies the behavior for
the value for states other
than execute.
→ "Semantics" section below
[default] = 0
26
Set
NV Safe value INT or speci-
fied by data
type
The Value to be used for
safe state = safe value
→ "Semantics" section below
[default] = 0
32
Get
NV Overrange INT or REAL
Specifies the highest valid
value.
The value above which attribute
reading valid
is set to invalid.
[default] = maximum allowable value
for the data type
33 Get
NV
Under-
range
INT or REAL
Specifies the lowest valid
value.
The value below which attribute
reading valid
is set to invalid.
[default] = minimum allowable value
for the data type
94 Get
V
Sensor
warning
Structure of
byte
Bit definitions of sensor
warnings.
default = 0
→ "Semantics" section below
95 Get
V
Sensor
alarm
Structure of
byte
Bit definitions of sensor
alarms.
default = 0
→ "Semantics" section below
4.4.3.13 User Adjust Service
Gain Adjust Request
Service Data Field
Parameters
4.4.3.14 PSG55x - Instance
Attributes of
Instance 1
