The output at the class attribute 94 (Active value) of the S-Analog

Sensor Object is always related to the current active instance (this could
be instance 1 or 2).
If you always want to have the same Active value in the idle or error
case the equal safe value must be set in both instances.

16 Bits are used as sensor faults. Sensor alarm byte 0 is mapped to the device
exception detail alarm 0, sensor alarm byte 1 is mapped to the device exception
detail alarm 1.

Data component

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Sensor alarm byte 0

0 0 0 0 0 0 0 0

Sensor alarm byte 1

0 0

0 0 0 0

Electronics

failure

0

16 Bits are used as sensor warnings. Sensor warning byte 0 is mapped to the
device exception detail warning 1, sensor warning byte 1 is mapped to the device
exception detail warning 2.

Data component

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Sensor warning byte 0

0 0 0 0 0 0 0 0

Sensor warning byte 1

0 0

0 0 0 0

Electronics

warning

0

8 Bits providing the current sensor alarm state of the instance. They are mapped to
device exception detail warning 0.

Data component

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Sensor alarm byte 0

0 0 0 0 0

Underrange

exceeded

Overrange

exceeded

Reading
invalid

1)

1)

Logical inversion of reading valid


The S-Analog Sensor Object provides the following common services:

Service

Code

Service Name

Description of Service

0E

h

Get_Attribute_Single

Returns the contents of the specified attribute.

10

h

Set_Attribute_Single

Modifies an attribute value.


The S-Analog Sensor Object provides the following common services:

Service

Code

Service Name

Description of Service

4B

h

Zero_Adjust

Used to calibrate the zero pressure value.


The Zero_Adjust service is used to cause the S-Analog sensor object device to
correct its offset error ones. This functionality can also be executed periodically by
setting the attribute 100 to true.

Parameter

Data Type

Description Semantics of Values

Zero_Adjust
parameter or target
value

UINT or
FLOAT
depending
on data
type

The target
value
for the zero
calibration

The value to which the
attribute 6 (value)
will be set  this value is
always "0". If not specified,
the default value of zero is
used.

Sensor alarm

Sensor warning

Status extension

4.4.3.3 Common Services

4.4.3.4 Object–Specific

Services

Zero_Adjust Request
Service Data Field
Parameters
