18

tira58e1-a (2012-03) PxG5xx.cp

This structure, similar in form to common exception detail, relates exception con-
ditions which are specific to individual devices on the network and are defined in
the following. The detail element of the structure is an ordered list (i.e. array) of
bytes of length [size = 2] which is the value of the structure element size.

This structure, similar in form to Common Exception Detail, relates exception con-
ditions which are specific to the manufacturers of individual devices on the network.
There is one byte manufacturer exception details defined. The Detail element of the
structure is an ordered list (i.e. array) of bytes of length [size = 1] which is the value
of the structure element size.



Data component

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Common exception detail
alarm size

0 0 0 0 0 0 1 0

Common exception detail
alarm 0

0 0 0

Data

memory

Nonvolatile

memory

Code

memory

0 0

Common exception detail
alarm 1

0 0 0 0 0 0 0 0

Device exception detail
alarm size

For PCG55x: 4
For PSG55x: 2

Device exception detail
alarm 0

S-Analog sensor instance 1, sensor alarm byte 0

(PCG55x: sensor instance 1 is a capacitance manometer)

(PSG55x: sensor instance 1 is a heat transfer vacuum gauge)

Device exception detail
alarm 1

S-Analog sensor instance 1, sensor alarm byte 1

(PCG55x: sensor instance 1 is a capacitance manometer

PSG55x: sensor instance 1 is a heat transfer vacuum gauge)

Device exception detail
alarm 2

PCG55x: S-Analog sensor instance 2, sensor alarm byte 0

PSG55x: not supported

Device exception detail
alarm 3

PCG55x: S-Analog sensor instance 2, sensor alarm byte 1

PSG55x: not supported

Manufacturer exception
detail alarm size

0 0 0 0 0 0 0 1

Manufacturer exception
detail alarm 0

0 0 0 0 0 0 0

SerCom

Alarm


Device exception detail

Manufacturer exception
detail

Exception detail alarm
(ID 15)
