INFICON PSG55x ATM to Medium Vacuum Gauge (DeviceNet) User Manual
Page 35

tira58e1-a (2012-03) PxG5xx.cp
35
Attribute
ID
Access rule NV/
V
Name
DeviceNet
data type
Description of attribute
Semantics of values
3 Set
NV
High
trip
point
INT or based
data type
attribute
Defines the value at or
above which a trip point
condition will occur.
→ "Semantics" section below
[default = defined by vendor]
4 Set
NV
High
trip
enable
BOOL
Enables the high trip point
setting.
[default = defined by vendor]
5 Set
NV
Low
trip
point
INT or based
data type
attribute
Defines the value at or be-
low which a trip point con-
dition will occur.
→ "Semantics" section below
[default = defined by vendor]
6 Set
NV
Low
trip
enable
BOOL
Enables the low trip point
setting.
[default = defined by vendor]
7 Get
V
Output
Status
BOOL
State of this object
instance.
0 = trip point condition does not exist
(unasserted)
1 = trip point condition exists
(asserted)
12 Get
NV
Destination
Packed
EPATH
Specifies the path of the
destination attribute whose
value will be set by output.
Path to attribute 3 of Instance 1 or 2
of DOP Object.
13
Get
V Output
BOOL
Output of the object the
value of which is sent to
destination.
= Status of the relay
14 Get
NV
Source
Packed
EPATH
Specifies the path of the
source attribute whose
value is retrieved for Input.
Path to attribute 6 of instance 1 of S-
analog sensor object
15
Get
V Input
INT or speci-
fied by data
type
Input to the object whose
value is retrieved from
source.
Value of attribute 6 of instance 1 of S-
analog sensor object
16
Get
NV Data units
ENGUNITS
Units of input, trip point.
17
Get
NV Data type
USINT
Data type of input.
[default] = INT
18 Set
NV
Trip
Point
High
Hysteresis
Same as
High/Low
Point
Data
Type
Determines the amount by
which the Input must
recover to clear a trip point
high condition
[default = defined by vendor]
19 Set
NV
Trip
Point
Low
Hysteresis
Same as
High/Low
Point
Data
Type
Determines the amount by
which the Input must
recover to clear a trip point
low condition
[default = defined by vendor]
20
Get
V Trip Status USINT
Describes the activator for
the trip point condition.
Activator may be a
High Trip Point condition
and/or a Low Trip Point
condition.
0 = no trip point condition exists
1 = low trip point condition exists
2 = high trip point condition exists
3 = high and low trip condition exist
4-255 = reserved
101 Set
NV
Factor
of
ATM
REAL
Multiplier for ATM control
If with the Attribute 102 the amt mode
is chosen, this value will be multiplied
with pressure value from S-Analog
Sensor Instance 3 (ATM sensor) and
copied into High or Low Trip Point
(
→ Attribute 102).
102 Set
NV
Setpoint
Mode
USINT
Mode of the setpoints
Atm Mode,
0 = standard setpoint
1 = LTP is in ATM Mode
2 = HTP is in ATM Mode
3 = LTP and HTP are in ATM Mode
4 … 7 = the same as 0 … 3, but the
change with push-buttons isn't al-
lowed
4.5.2 Instance Attributes of
Trip Point Objects
Instance 1 & 2
