Following is the instance 2 with the subclass extension of the heat transfer mano-
meter part of the gauge (valid for PCG55x).

Attribute

ID

Access rule NV/

V

Name

DeviceNet
data type

Description of attribute

Semantics of values

3

"Semantics"

NV Data

type USINT

Determines the data type of
value

and all related attributes

as specified in this table.

→ "Semantics" section below
[default] = INT

4

"Semantics"

NV Data

units UINT

Determines the units context
of value and all related attrib-
utes.

[default] = Counts

5 Get

V

Reading
valid

BOOL

Indicates that the value attrib-
ute contains a valid value.

0 = invalid
1 = valid
(invalid: e.g., sensor is out of its specified
range)

6

Get

V Value

INT or REAL

Analog input value.

The corrected, converted, calibrated final
value of the sensor.
→ "Semantics" section

7 Get

V

Status

BYTE

Alarm and warning state of
this object instance.

= 0

10

Get

NV Full scale

INT or REAL

The value of full scale for the
sensor.

[default] = maximum allowable value for
the data type

25 Set

NV

Safe

state

USINT

Specifies the behavior for the
value

for states other than

execute.

→ "Semantics" section below
[default] = 0

26

Set

NV Safe value INT or speci-

fied by data
type

The Value to be used for safe
state = safe value

→ "Semantics" section below
[default] = 0

32

Get

NV Overrange INT or REAL

Specifies the highest valid
value.

The value above which attribute reading
valid

is set to invalid.

[default] = maximum allowable value for
the data type

33 Get

NV

Under-
range

INT or REAL

Specifies the lowest valid
value.

The value below which attribute reading
valid

is set to invalid.

[default] = minimum allowable value for
the data type

94 Get

V

Sensor
warning

Structure of
byte

Bit definitions of sensor warn-
ings.

default = 0
→ "Semantics" section below

95 Get

V

Sensor
alarm

Structure of
byte

Bit definitions of sensor
alarms.

default = 0
→ "Semantics" section below

96 Get

V

Status
extension

Byte

Bit-mapped byte providing
additional status bits of an S-
Analog sensor instance.

default = 0
→ "Semantics" section below

99 Get

V

Subclass

UINT

Identifies a subset of addi-
tional instance attributes, ser-
vices and behaviors.

2 = Heat Transfer Vacuum Gauge

101 Set

NV

Pirani

OFF

Cmd

USINT

Flag to switch off the Pirani in
a dangerous environment

0 = Pirani is always on;
1 = Pirani switches off at 120% of
s32CombineUpperLimit;
2 = Pirani is always off

If the Pirani is switched off, the measure-
ment part (wheatstone bridge) is not
powered and the instance outputs it’s
"Safe State" value

In this case the Status extension is also
set to "Reading Invalid"

102 Set

NV

Pirani
Adjust Hv
Pressure

INT or speci-
fied by data
type

Target value for the high
vacuum (hv) adjustment

<1E-4mbar = standard hv adjustment,
other values = adjustment to this value


4.4.3.6 PCG55x - Instance

Attributes of Instance 2
