Data component

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Common exception detail
warning size

0 0 0 0 0 0 1 0

Common exception detail
warning 0

0 0 0

Data

memory

Nonvolatile

memory

Code

memory

0 0

Common exception detail
warning 1

0 0 0 0 0 0 0 0

Device exception detail
warning size

For PCG55x: 5
For PSG55x: 3

Device exception detail
warning 0

S-Analog sensor instance 1, Class level status extension

Device exception detail
warning 1

S-Analog sensor instance 1, sensor warning byte 0

(PCG55x: sensor instance 1 is a capacitance manometer

PSG55x: sensor instance 1 is a heat transfer vacuum gauge)

Device exception detail
warning 2

S-Analog sensor instance 1, sensor warning byte 1

(PCG55x: sensor instance 1 is a capacitance manometer

PSG55x: sensor instance 1 is a heat transfer vacuum gauge)

Device exception detail
warning 3

S-Analog sensor instance 2, sensor warning byte 0

PSG55x: not supported

Device exception detail
warning 4

S-Analog sensor instance 2, sensor warning byte 1

PSG55x: not supported

Manufacturer exception
detail warning size

0 0 0 0 0 0 0 1

Manufacturer exception
detail warning 0

0 0 0 0 0 0 0

SerCom
Warning


These boolean attributes are used to enable (1) or disable (0) the S-Device super-
visor object’s process of setting exception bits. When disabled, corresponding bits
are never set; and, if they were set, disabling clears them. Also, alarm and warning
states are not retained; when enabled, bits will be set only if the corresponding
condition is true.
The default state for these enable attributes is enabled (1).

Exception detail warning
(ID 16)

Alarm enable and warning
enable
