10

tira58e1-a (2012-03) PxG5xx.cp

A single, rotary switch is provided for configuring the data rate of the device. The
switch has three valid positions for the DeviceNet data rates, 125, 250, and
500 kBaud, where:

1

≙ 1

25 kBaud

2

250 kBaud

5

500 kBaud

Example: Data rate = 250 kBaud:

RATE

2

All remaining switch positions specify software selection of the data rate.

Abbr.

Meaning

NV

Nonvolatile; attribute value is maintained through power cycles

V Volatile

USINT

Unsigned short integer value

(Range 0 … 255)

INT

Integer value

(Range –32767 … 32768)

UINT

Unsigned integer value

(Range 0 … 65635)

UDINT

Unsigned double integer value (Range 0 … 4'294'967'295)

FLOAT

Floating point value

(Range according to IEEE 754)

XX

h

Hexadecimal number

(Radix = 16)

XX

d

Decimal number

(Radix = 10)

XX

b

Binary number

(Radix = 2)


The EDS (Electronic Data Sheet) file can be used for the automatic setup of the
gauge with a configuration tool. It can be downloaded from our website (

→  [5]).

The package contains two directories: INT and REAL.
• INT directory: It contains the presetting for the parameters in- and output in the

integer format

. The I/O default assembly object is two.

• REAL directory: It contains the presetting for the parameters in- and output in

the real format. The I/O default assembly object is five.


3.3.4 Data Rate Switch

3.4 Abbreviations

3.5 EDS File
