tira58e1-a (2012-03) PxG5xx.cp

23

Following is the instance 1 with the subclass extension of the capacitance mano-
meter (diaphragm gauge) part of the gauge (valid for PCG55x).

Attribute

ID

Access rule

NV/

V

Name

DeviceNet data
type

Description of
attribute

Semantics of values

3

"Semantics"

section below

NV Data type

USINT

Determines the data
type of value and all
related attributes as
specified in this table.

→ "Semantics" section below.
Int

≙ C3

h

[default]

float

≙ CA

h

4

"Semantics"

section below

NV Data units

UINT

Determines the units
context of value and
all related attributes.

→ "Semantics" section below.
Supported Values:
Counts

≙ 1001

h

[default]

mbar

≙ 1308

h

Torr

≙ 1301

h

Pascal

≙ 1309

h

5 Get

V

Reading

valid

BOOL

Indicates that the
value

attribute con-

tains a valid value.

0 = invalid
1 = valid
(invalid: e.g., sensor is out of its
specified range)

6

Get

V Value

INT or specified
by data type

Analog input value

The corrected, converted, calibrated
final value of the sensor.
→ "Semantics" section below.

7 Get

V

Status

BYTE

Alarm and warning
state of this object
instance.

→ "Semantics" section below.

10

Get

NV Full Scale

INT or specified
by data type

The value of full scale
for the sensor.

The value of attribute value
corresponding to the full scale
calibrated measurement of the
sensor.
[default] = maximum allowable
value for the data type

25 Set

NV Safe

state USINT

Specifies the be-
havior for the value
for states other than
execute

→ "Semantics" section below.

[default] = 0

26

Set

NV Safe value

INT or specified
by data type

The value to be used
for safe state = safe
value

→ "Semantics" section below.

[default] = 0

32

Get

NV Overrange

INT or specified
by data type

Specifies the highest
valid value

The value above which attribute
reading valid

is set to invalid.

[default] = maximum allowable
value for the data type

33

Get

NV Underrange

INT or specified
by data type

Specifies the lowest
valid value

The value below which attribute
reading valid

is set to invalid.

[default] = minimum allowable value
for the data type

94

Get

V Sensor warning

Struct of byte

Bit definitions of
sensor warnings

0 = [default]
→ "Semantics" section below

95

Get

V Sensor alarm

Struct of byte

Bit definitions of
sensor alarms

0 = [default]
→ "Semantics" section below

96 Get

V

Status

extension

BYTE

Bit-mapped byte pro-
viding additional sta-
tus bits of an S-Ana-
log sensor instance.

0 = [default]
→ "Semantics" section below

99 Get

NV Subclass UINT

Identifies a subset of
additional instance
attributes, services
and behaviors.

3 = Capacitance Manometer

100

Set

NV Auto Zero Adjust

BOOL

Used to calibrate the
CDG Zero pressure
value periodically

0 -> deactivated;
1 -> activated [default];


4.4.3.1 PCG55x - Instance

Attributes of Instance 1
