14

tira58e1-a (2012-03) PxG5xx.cp


Attribute ID

Access rule NV/

V

Name

DeviceNet data type

Description of attribute

3

Get

NV Devicetype

SHORT STRING

ASCII Text, "VG" (vacuum gauge) for
PSG55x; “CG” for PCG55x

4 Get

NV

SEMI

standard

revision level

SHORT STRING

Specifies the revision level of the SEMI
S/A network standard to which the device
complies (for example "E54-0997").

5

Get

NV Manufacturer’s name

SHORT STRING

"INFICON AG" (default)

6 Get

NV

Manufacturer’s

model

number

SHORT STRING

ASCII text, manufacturer specified

7

Get

NV Software revision level SHORT STRING

ASCII text, Revision of the DeviceNet
board software, for example "010200"

8 Get

NV

Hardware

revision

level

SHORT STRING

ASCII text, for example "1.000"

9 Get

NV

Manufacturer’s

serial

number

SHORT STRING

ASCII text

10

Get

NV Device configuration

SHORT STRING

→ "Semantics" section below.

11 Get

V

Device

status USINT

→ "Semantics" section below.

12 Get

V

Exception

status

BYTE

→ "Semantics" section below.

13 Get

V

Exception detail
alarm

STRUCT of:

A structure of three structures containing
a bit mapped representation of the alarm
detail

Common
exception detail

STRUCT of:

Size 2

USINT

Number of common detail bytes

Detail 0

ARRAY of:

→ "Semantics" section below.

Detail

1

BYTE

→ "Semantics" section below.

Device exception
detail

STRUCT of:

Size

USINT

Number of device detail bytes
→ "Semantics" section below.

Detail

0

→ "Semantics" section below.

Detail

1

→ "Semantics" section below.

Detail

2

→ "Semantics" section below.

Detail

3

→ "Semantics" section below.

Manufacturer
exception detail

STRUCT of:

Size 1

USINT

Number of manufacturer detail bytes

Detail 0

ARRAY of:

Manufacturer Specified


4.3.2 Instance Attributes
