tira56e1 (2010-02) PxG55x.cp
7
1 Technical Data
Further technical data → [1], [2]
Fieldbus name Profibus
Standard applied → [5]
Communication protocol data format → [5]
Interface, physical RS485
Data rate ≤12 MBaud
→ [5]
Node address
Local
(Adjustable via hexadecimal
"ADDRESS", "MSD", "LSD"
switches)
Default setting
Via Profibus
(hexadecimal "ADDRESS" switches
set to >7d
hex
(>125
dec
))
00 … 7D
hex
(0 … 125
dec
)
01
hex
00 … 7D
hex
(0 … 125
dec
)
Profibus connection D-Sub, 9-pin, female
Cable shielded, special Profibus cable
→ 9 and [5]
Cable length, system wiring according to Profibus specifications
→ [5]
Profibus interface
