INFICON PSG55x ATM to Medium Vacuum Gauge (Profibus) User Manual
Page 11
tira56e1 (2010-02) PxG55x.cp
11
THE "NET" LED indicates the network status of the PxG55x gauge:
LED
Status
Off
Device is off
Red
Error. The alarm bit in Exception Status is set (
→ 26).
Green/flashing Device is ok and uses acyclic data traffic (→ 14).
Green
Device is ok and uses cyclic data traffic (
→ 15).
The gauge supports all data rates defined in the IEC 61158 Type 3 / IEC 61784
standards (
→ [5]) up to 12 MBaud. Automatic data rate setting is supported.
Alternatively, a fixed data rate can be selected.
The ident number assigned to the gauge by the PNO (
→ [4]) is:
Gauge
Ident number (hexadecimal)
PxG55x 0x0C85
3.4 "NET" LED
3.5 Data Rate
3.6 Ident Number
