INFICON PSG55x ATM to Medium Vacuum Gauge (Profibus) - Manual (Page 25)

tira56e1 (2010-02) PxG55x.cp
25
This parameter provides the current device configuration, e.g. " DS9 SP WO ATM
PB CDG AO0 PIR".
The following abbreviations are used:
Abbreviation Description
DS9 D-Sub connector 9-pin
FCC FCC connector
HM Hirschmann connector
DS15HD D-Sub connector 15-pin HD
SP Setpoints
PS Potential
separation
WO Tungsten filament
NI Nickel filament
ATM Atmosphere sensor
DIS Display
DN DeviceNet
PB Profibus
RS1 RS485 protocol 1
RS2 RS485 protocol 2
RS3 RS485 protocol 3
RS4 RS485 protocol 4
CDG Capacitance Diaphragm sensor
AO0 8.5 V analog out
AO1 10 V analog out
AO3 Special analog out
TTR21X TTR21X compatibility
PIR Heat Transfer (Pirani) vacuum sensor
ION Hot- / Cold-Ionization vacuum sensor
This parameter indicates the overall status of the gauge. Due to the structure of the
Device State Machine, the following states are possible:
Parameter value Status
0 Undefined
1 Self testing
2 Idle
3
Self test exception
4 Executing
5 Abort
6 Critical
fault
7…50 Reserved by PNO
51…99 Device-specific
100…255 Manufacturer-specific
7.1.9 Device Configuration
(ID 24)
7.1.10 Device State (ID 25)
