40
tira56e1 (2010-02) PxG55x.cp
This function block describes the functionality of the Atmosphere Pressure Sensor
measuring part of the gauge.
The PSG55x and some variants of the PCG55x do not have a Atmos-
phere Pressure Sensor (ATM) and this function block (ATM) is not sup-
ported.
The following attributes are supported:
ID Name Structure Data type Bytes Access Store →
15 AIBlockAdjust Command Record UINT8 2 1_R/W
2_R/W
N 40
16 Block Type ID Simple OSTRING(n) 4 1_R
2_R N 41
19 ProcessValue (PV) Simple *) - 0_XI
1_R
2_R
D 41
20 Status Simple UINT8 1 0_XI
1_R
2_R
D 41
21 Data Type Simple 1 2_R/W N 41
22 Data Unit Simple UINT16 2 2_R/W N 41
23 Reading Valid Simple Boolean 1 1_R
2_R
D 42
24 Full Scale Simple *) - 1_R
2_R
N 42
39 Safe State Simple UINT8 1 1_R/W
2_R/W
N 42
40 Safe Value Simple *) - 1_R/W
2_R/W
N 42
44 Overrange Simple *) - 1_R
2_R
N 42
45 Underrange Simple *) - 1_R
2_R
N 42
*) According to data type value (ID 21)
Byte Name Structure Data Type Bytes Access Store
0 Adjust
Command
Simple UINT8 1 1_R/W
2_R/W
N
1 Target Value Simple *) 1 1_R/W
2_R/W
N
*) According to data type value (ID 21)
Adjust Command Name Description
0
2…255
Reserved Reserved, no action
1 Gain Adjust If this service is performed, the ATM sensor
value will be set to the same value as at that
time measured by the diaphragm gauge.
Target value Description
0…255 Not available
To perform the Gain Adjust vent to atmosphere and then start the Gain Adjust
Service.
8.3 Sensor Analog Input
Function Block
(ATM)
8.3.1 Analog Input Block
Adjust Command
(ID 15)
Gain adjust algorithm
