Appendix B: Block Type
Block Name
Block Type ID
Device Block
1
Sensor Analog Input Function Block
2
One of N Channel Sensor Analog Input Function Block
3
Multi Channel Sensor Analog Input Function Block
4
Discrete Input Function Block
5
Actuation Analog Output Function Block
6
Discrete Output Function Block
7
Analog Output Function Block
8
Single Stage Controller Function Block
9
Gas Calibration Transducer Block
10
Flow Transducer Block
11
Sensor Analog Input Ambient Temperature Transducer Block
12
Heat Transfer Vacuum Gauge
13
Diaphragm Gauge
14
Cold Cathode Ion Gauge
15
Hot Cathode Ion Gauge
16
Trip Point Function Block
17
OneOfN Vacuum Pressure Gauge Transducer Block
18
Reserved
19 … 2
8
- 1
Manufacturer-specific 2
8
… 2
16
- 1
Currently defined Block Types
