INFICON PSG55x ATM to Medium Vacuum Gauge (Profibus) - Manual (Page 52)

52
tira56e1 (2010-02) PxG55x.cp
This transducer block can only be accessed if the ATM sensor is part of the device
configuration (ID 24) (
→ 25).
ID Name Structure Data type Bytes Access Store →
101 Block Type ID Simple OSTRING(n
) 4 1_R
2_R
N 52
102 Status
Extension
Simple UINT8 1 1_R
2_R
V 52
103 Sensor Alarm Array UINT8 2 1_R
2_R V 52
104 Sensor Warning Array UINT8 2 1_R
2_R V 52
The Block Type ID Parameter contains an ID which describes the block type. The
block type ID of the "ATM Transducer Block" is set to "256". The other defined
block types are listed in Appendix B.
This bit mapped byte parameter provides the following additional information of the
ATM sensor (ATM):
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Res. Res. Res. Res. Res. Underrange
Exceeded
Overrange
Exceeded
Reading
Invalid
Res. = Reserved
• Underrange
Exceeded
This bit is set ("1") if the ProcessValue PV is below the parameter Underrange
(ID 45) of the ATM sensor instance (
→ 42).
• Overrange Exceeded
This bit is set ("1") if the ProcessValue PV is above the parameter Overrange
(ID 44) of the ATM sensor instance (
→ 42).
• Reading invalid
This bit represents the logical inversion of the parameter "Reading Valid"
(ID 23) of the ATM sensor instance (
→ 42).
This parameter contains the following information:
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Byte 0 0 0 0 0 0 0 0 SF
Byte 1 0 0 0 0 0 0 EF 0
• SF = Sensor Element Failure
• EF = Electronics Failure
This byte is always "0". (The ATM Sensor does not produce any warnings).
12.3 ATM Transducer Block
12.3.1 Block Type ID (ID 101)
12.3.2 StatusExtension
(ID 102)
12.3.3 Sensor Alarm (ID 103)
12.3.4 Sensor Warning (ID 104)
