28
tira56e1 (2010-02) PxG55x.cp
The parameter contains an array of 8 bytes, which are assigned as follows:
Byte
no
Name Description Value
Common Exception Detail Alarm
0 Size Number of subsequent bytes
used for description of the alarm
(simple, UINT8, 1 byte) 2
1 Detail 0 Error message
(simple, UINT8, 1 byte) → table 28
2 Detail 1 Error message
(simple, UINT8, 1 byte) → table 28
Device Exception Detail Alarm
3 Size Number of subsequent bytes
used for description of the alarm 2
4 Detail 0
5 Detail 1
Error message
(array, UINT8, 2 bytes)
Sensor Alarm (Inst. 1,
ID 103) of PSG55x
Transducer Block
→ 50
Manufacturer Exception Detail Alarm
6 Size Number of subsequent bytes
used for description of the alarm
(simple, UINT8, 1 byte) 1
7 Detail Error message
(simple, UINT8, 1 byte)
→ table 28
Bit Common Exception Detail 0 Bit Common Exception Detail 1
0 Internal diagnostic exception 0 0
1 Microprocessor exception 1 0
2 EPROM exception 2 0
3 EEPROM exception 3 0
4 RAM exception 4 0
5 Communications exception 5 0
6 Internal real-time exception 6 0
7 0 7 0
Bit Manufacturer Exception Detail
0 Internal communication
exception
1 Incompatible software
2 0
3 0
4 0
5 0
6 0
7 0
PSG55x
Common Exception
Detail Alarm / Warning
Manufacturer Exception
Detail Alarm / Warning
