10 Discrete Output Function Block (Relay 1 and 2)
The Discrete Output Function Block is used for switching the relays on and off. The
following attributes are supported:
ID Name Structure Data Type Bytes Access Store →
16 Block Type ID Simple OSTRING(n) 1 1_R
2_R N 44
19 Setpoint Value Simple UINT8 1 0_XO
2_R
D 44
20 Status Simple Boolean 1 2_R D 44
The Block Type ID Parameter contains an ID which describes the block type. The
block type ID of the "Discrete Output Function Block" is set to "7". The other de-
fined block types are listed in Appendix B.
This parameter contains the value which is forwarded to the relay:
Setpoint value Relay
0 Off
1 On
2…255 Off
This parameter indicates the state of the Discrete Output Function Block Instance.
Status Description
0 Ok
1
Error or alarm
10.1 Information on the
Individual Indices
10.1.1 Block Type ID (ID 16)
10.1.2 Setpoint Value (ID 19)
10.1.3 Status (ID 20)
